Supply Ability
Packaging & delivery
Quantity(pieces) | 1 - 10 | >10 |
Lead time (days) | 15 | To be negotiated |
Product Display
Model | XPC5kw+5.12kwh/10.24kwh/15.36kwh/20.48kwh/25.6kwh |
stacked lithium battery | |
Single module capacity | 5.12kwh |
Module number | 1/2/3/4/5pcs |
Total capacity | 5.12kwh/10.24kwh/15.36kwh/20.48kwh/25.6kwh |
Standard voltage | 51.2V |
Working voltage | 43.2V-57.6V |
Standard discharge current | 100/200/300/400/500A |
Standard charging current | 50/100/150/200/250A |
Suggested DOD | 80% |
Humidity | 20%-60% |
Installation | Stacked |
IP rating | IP20 |
Communication | CAN/RS485/RS232(WIFI,bluetooth is optional and need extra cost) |
Product size/unit | 550*500*185mm |
N.W./unit | 40kgs |
Battery Input | |
Battery type | LFP |
Rated Battery Input Voltage | 48V ( Minimum Star tup Voltage 44V) |
Hybrid Charging Maxi mum Charging Current | 80A |
Battery Voltage Range | 40VDC~60VDC ± 0.6VDC(Under voltage Warning/Shutdown Voltage/Over voltage Warning/Over voltage Recover y...) |
Solar Input | |
Maximum PV Open-circuit Voltage | 500vDC |
PV Working Voltage Range | 120-500VDC |
MPPT Voltage Range | 120-450VDC |
Maximum PV Input Current | 18A |
Maximum PV Input Power | 5200W |
Maximum PV Charging Current | 80A |
AC Input(generator/grid) | |
Mains Maximum ChargingCurrent | 60A |
Rated Input Voltage | 220/230VAC |
Input Voltage Range | UPS Mains Mode:(170VAC~280VAC)±2% APL Generator Mode:(90VAC-280VAC)±2% |
Frequency | 50Hz/ 60Hz (Automatic Detection) |
Mains Charging Efficiency | >95% |
Switch Time (bypass and inverter) | 10ms(Typical Value) |
Maximum Bypass Overload Current | 40A |
AC Output | |
Output Voltage Waveform | Pure Sine Wave |
Rated Output Voltage (VAC) | 230VAC (200/208/220/240VAC) |
Rated Output Power (VA) | 5000(4350/4500/4800/5000) |
Rated Output Power(W) | 5000(4350/4500/4800/5000) |
Peak Power | 10000VA |
On-load Motor Capacity | 4HP |
Output Frequency Range(Hz) | 50Hz±0.3Hz/60Hz±0.3Hz |
Maximum Efficiency | >90% |
No-load Loss | Non Energy-saving Mode: ≤50W Energy-saving Mode:≤25W (Manual Setup) |
